160-200hp 4*4 farm big tractor
Rayho-160-200HP 4*4 big tractor is universally used in flat, sloping, paddy fields, etc multiple terrains.
It has good possibility, traction force and PTO output. And finish rotary tillage, sowing, fertilization, cultivating, harvesting, transportation, engineering with farm accessories, etc.
it has high fuel efficiency, low maintenance cost and good working performance with Chinese famous brand diesel engine.
Product Description
160-200hp 4*4 big farm tractor
| Model | RH1604A | RH1804A | RH2004A | ||
|
Basic Information | Size(mm) | 4990*2320*3130 | |||
| Rated power(kw) | 117.7 | 132.4 | 147.1 | ||
| Min operating weight(kg) | 5150 | 5866 | 6200 | ||
| Wheel base | 2638mm | ||||
| Drive Type | 4×4 Drive | ||||
| Min Ground Clearance | 440mm | ||||
| Tread(mm) | 1820(1620～1950)Adjustable | ||||
| Match Power | Engine brand | 6 cylinder YTO | |||
| Clutch type | Dry-type, double-acting | ||||
| Rated speed | 2200(r/min) | ||||
| Working Part | Gear | TF/TC 16F+8R | |||
| PTO type | 8Pin,Φ38,I Type(Option: 6Pin) | ||||
| PTO rated power(kw) | ≥100.3 | ≥112.6 | ≥125 | ||
| PTO speed (r/min) | 760/850,760/1000,540/1000 | ||||
| Hydraulic System
| Hydraulic output | 3-Way valve | |||
| 3 Point linkage | Rear, three-point suspension,CAT1 | ||||
| Adjustment model | Forced hydraulic system, position control, floating control | ||||
| Max.lift-off force(KN) | ≥28.3 | ≥31.8 | ≥35.3 | ||
| Standard tire type | Front | 12.4-24 | 14.9-26 | 14.9-26 | |
| Rear | 16.9-34 | 18.4-38 | 18.4-38 | ||
| Other options | Optional: heating cabin, A/C cabin, tires, etc. | ||||
6 Things You Need To Know Before Buying Tractor
What is your purpose?
-You buy it for yourself or as a wholesale.
Where to use it?
– In paddy fields, dry land.
-on flat big farm, or on small garden, narrow greenhouse, Greenhouse, Orchard, etc.
What is the main function for a tractor?
-mowing, tilling, plowing, etc farm working.
-loading, excavation, backhoe, etc engineering working.
Which part is import for a quality tractor?
-Diesel engine, Hydraulic output, 3 Point linkage, PTO type, Tire type, Clutch type, Gear box.
What farm tools do you need?
Tractor and farm implements should use as a whole.
Whether have good sales service for supplier?
-special product knowledge, Installation Services, good after-sales service.
What benefits can we bring to you?
1).Tractor models: Our tractors are affordable, long service life, tractor models are from 8HP to 280HP.
2).Customization: Color choice, Tractor configuration, trademarks, etc.
3).Discounts and Price:
-We give you more discounts to open the market for new clients.
-We provide you with enough profit margin based on the needs of different customers.
4). Big Tractor Quality:
-We have CE certification.
– Always a pre-production sample before mass production.
-Finish 100% inspection before shipment.
5).After sales service of big tractor:
-1 year warranty service of diesel engine.
-sufficient inventory of farm tractor and farm tools,.
-free product install and market training.
-help clients purchase matched agriculture tools to save time and money.
6).Visualization of big tractor:
-We support clients visitation.
-Tractor process, packing and transportation are open for you.
Rayho machinery is a professional factory of farm and forest machinery. Main Products
are Walking tractor, 4WD mini tractor,4WD small tractor, 4WD farm tractor,
Crawler tractor,Power tiller, Mower machine,Harvester machine,Sprayer machine,
Thresher machine, Garden Machinery, etc 15 series products,
We are Reliable supplier of China Government Agricultural Projects for 6 years. We pass
ISO 9001 international quality standards and have CE certification.
Rayho focus on Product Quality and provide the Best Solution.
